IP67 rated camera housing for deploying a camera kit in harsh environments

Stable and flexible solution for mounting VIOSO camera kits on walls

ca. 1,30m height, integrated ballhead, compatible to all VIOSO calibration kits

1.1'' sensor + 6 lenses (6.5, 8, 12, 16, 25, 50mm) & 1'' sensor + 2.7mm fisheye lens

1.8'' sensor + 5 lenses (1.3, 1.67, 3.5, 4, 6mm) & 2/3'' sensor + 1.8mm fisheye lens

1/1.8'' 6MP GigE sensor, 44,7° x 33,9° FOV

1/1.8'' 6MP GigE sensor, 29,9° x 21,9° FOV

1.1'' 12MP GigE sensor, choose from 8, 12, 16, 25 or 50 mm fixed focus lens

1/2.3'' 10MP GigE sensor, 280° x 280° equisolid fisheye lens

1/2.3'' 10MP GigE sensor, 250° x 250° equisolid fisheye lens

1'' 16MP GigE sensor, 2.7mm lens, 185°x185° equidistant fisheye lens

- 2/3'' chip camera, 4MP resolution, 1 GB/s network interface
- 1.8mm fisheye lens (ca 360°x185°)
- incl. PoE-injector, tripod adaptor, rugged transport case

Note: use only for spherical screens and cylinders, not suitable for multicam-calibrations!

1/2.5'' 5MP GigE sensor, 135 x 119° FOV

2/3'' 5MP GigE sensor, 3.5mm lens, 100°x84° FOV, multicam-ready

1.1'' 12MP GigE sensor, 95° x 78° FOV, multicam-ready

- 1/1.8'' chip camera, 6MP resolution, 1GB/s network interface
- very low distortion wide angle lens (89° x 73° FOV)
- incl. PoE-injector, tripod adaptor, rugged transport case
- multicam-ready

1/1.8'' 6MP GigE sensor, 76° x 60° FOV, multicam-ready

1/1.8'' 6MP GigE sensor, 56,8° x 44,0° FOV, multicam ready

variable 53cm mounting arm with clamp mount; compatible to all VIOSO calibration kits

1/2.5'' chip camera, 5MP resolution, 1 GB/s network interface
1.8mm ultra wide angle lens (120° horizontal field of view)
incl. PoE-injector, tripod adaptor, rugged transport case

Caution:
- Lens has strong distortion, manual correction necessary. Should be aligned as centred as possible on the projection surface
- Only suitable for planar surfaces and not suitable for multicam calibrations!
